| Specification | Details |
|---|---|
| Manufacturer | Enphase Energy |
| Model | IQBATTERY-5P-1P-NA-DOM |
| Product Type | AC-Coupled Battery Storage System |
| Usable Capacity | 5.0 kWh |
| Total Capacity | 5.0 kWh |
| Continuous Output Power | 3.84 kVA |
| Peak Output Power | 7.68 kVA (3 sec), 6.14 kVA (10 sec) |
| Nominal Voltage | 240 VAC |
| Nominal Frequency | 60 Hz |
| Rated Output Current | 16 A |
| Peak Output Current | 32 A (3 sec) |
| Battery Chemistry | Lithium Iron Phosphate (LFP) |
| AC Round-Trip Efficiency | ~90% |
| DC Round-Trip Efficiency | ~96% |
| Operating Temperature (Charge) | -20°C to 50°C (-4°F to 122°F) |
| Operating Temperature (Discharge) | -20°C to 55°C (-4°F to 131°F) |
| Dimensions | 38.6 × 21.7 × 7.4 in |
| Weight | 174 lb installed |
| Enclosure Rating | NEMA 3R (Outdoor Rated) |
| Communication | Wired Control Communication |
| Compatibility | Enphase IQ Microinverters, IQ System Controller 3/3G, IQ Combiner, IQ Gateway |
| Mounting | Wall-Mount or Pedestal (Optional) |
