590W Black Frame N-Type TOPCon Bifacial Solar Module
The Axitec AXIworldbiperfect GXXL 590W (AC-590TGB/144/FS30/BF) combines high-efficiency N-Type TOPCon bifacial cell technology with a modern, high-aesthetic black anodized frame. Built with dual-glass (glass/glass) encapsulation, this 144 half-cell module captures sunlight from both sides to deliver maximum kilowatt-hour (kWh) performance over its long operational lifespan.
This module is FEOC Free, offering developers, contractors, and investors a compliant, high-yield PV solution tailored to current market standards.
Key Features & Benefits
-
FEOC Free Compliance: Engineered to meet market requirements regarding Foreign Entity of Concern regulations.
-
Up to +30% Bifacial Boost: Dual-glass design with transparent cell spacing allows rear-side light absorption for up to 30% extra power generation.
-
Black Frame Aesthetics: Features a sleek 30mm black frame (BF) that pairs strong mechanical strength with an attractive visual profile.
-
Low Degradation N-Type Tech: Minimizes PID and LID effects with a guaranteed 87.4% linear power retention at year 30.
Specifications (Datasheet Verified)
1. Electrical Data (STC 1000 W/m²)
-
Nominal Output (Pmpp): 590 Wp
-
Nominal Voltage (Umpp): 44.23 V
-
Nominal Current (Impp): 13.36 A
-
Open Circuit Voltage (Uoc): 52.90 V
-
Short Circuit Current (Isc): 14.11 A
-
Module Conversion Efficiency: 22.84%
2. Bifacial Output (BNPI Test Conditions: Front 1000 W/m² + Back 135 W/m²)
-
BNPI Nominal Output (Pmpp): 651 Wp
-
BNPI Short Circuit Current (Isc): 15.56 A
-
BNPI Open Circuit Voltage (Uoc): 52.90 V
3. Mechanical Data
-
Dimensions (L x W x H): 89.69 x 44.65 x 1.18 in (2278 x 1134 x 30 mm)
-
Weight: 69.45 lbs (31.5 kg) with frame
-
Frontside Glass: 2.0 mm low-reflection white tempered glass
-
Backside Glass: 2.0 mm tempered glass (cell spaces transparent)
-
Frame: 1.18 in (30 mm) Black Anodized Aluminum Frame (BF)
-
Junction Box: IP68 Protection Class, 3 bypass diodes
-
Connectors: Stäubli MC4-EVO 2A
-
Cable Length: 51.18 in (1300 mm), AWG 12
4. Operating Limits & Temperature Coefficients
-
Maximum System Voltage: 1500 VDC (UL / IEC)
-
Max Reverse Current Feed: 30.0 A
-
Temperature Coefficient (Pmpp): -0.31 %/K
-
Temperature Coefficient (Uoc): -0.28 %/K
-
Temperature Coefficient (Isc): +0.046 %/K
-
Packaging: 36 pieces per pallet / 720 pieces per 40' HC container
