Product Description
Functional Benefits and Target Users for Sustainable Energy
Designed for residential and commercial customers seeking reliable renewable power, this Axitec 460W GXXL panel offers an ideal balance of efficiency and durability. End users requiring enhanced energy harvest will appreciate its solar panel bifacial design that captures sunlight on both sides. Perfect for those investing in long-term, clean energy solutions, this module’s black anodized aluminum frame provides a sleek aesthetic combined with strong environmental protection. Homeowners, business operators, and small-scale project developers can confidently integrate this black solar panel into their solar systems to increase power output and dependability.
Technical Features and Measurable Performance Data
Constructed with cutting-edge N-Type cell technology, the panel reaches a module efficiency of up to 23.02%, representing superior performance among contemporary n type solar panels. The glass/glass structure enhances lifespan and mechanical strength, enduring harsh conditions from -40°C to +85°C, with a certified mechanical load resistance of 75.3 PSF. Equipped with robust IP68-rated junction boxes and Stäubli MC4-EVO2 connectors, the panel supports up to 1500V DC system voltage, making it compatible with high-voltage solar arrays. Its 460W nominal output and 96 half-cell configuration optimize power yield reliably across varied installations.
Industry Applications and Practical Impact on Solar Projects
This solar panel bifacial unit is engineered to meet the needs of grid-tied, off-grid, and commercial-scale solar farms requiring high energy density and system resilience. Its advanced cell technology enables enhanced energy production for homes, businesses, and utility projects alike. The panel’s robust construction and superior efficiency mean reduced Levelized Cost of Energy (LCOE) while ensuring compliance with industry standards. Widely applicable in retrofit projects to upgrade existing installations or new developments prioritizing power maximization, the product is a versatile choice supporting sustainable energy strategies globally. Additionally, durability and ease of system integration accelerate deployment and operational reliability.
|
Type
|
AC-460TGB/96BB
|
|
Nominal output
|
460 Wp
|
|
Nominal voltage Umpp
|
32.25V
|
|
Nominal current Impp
|
13.80A
|
|
Nominal current Impp
|
14.53A
|
|
Open circuit voltag Uoc
|
38.64V
|
|
Module conversion efficiency
|
23.02 %
|
| Specification |
Details |
| Manufacturer |
AXITEC |
| Model |
AC-460TGB/96/FS30/BF |
| Series |
AXIworldblackbiperfect GXXL |
| Cell Technology |
N-Type Bifacial, Glass/Glass |
| Cell Configuration |
96 Half-Cells |
| Maximum Power (Pmax) |
460 W |
| Module Efficiency |
Up to 23.02% |
| Maximum Power Voltage (Vmp) |
32.25 V |
| Maximum Power Current (Imp) |
13.80 A |
| Open Circuit Voltage (Voc) |
38.64 V |
| Short Circuit Current (Isc) |
14.53 A |
| Temperature Coefficient (Pmax) |
-0.30% / °C |
| Temperature Coefficient (Voc) |
-0.25% / °C |
| Temperature Coefficient (Isc) |
+0.045% / °C |
| Nominal Operating Cell Temperature (NOCT) |
45°C ± 2°C |
| Maximum System Voltage |
1500 V DC |
| Maximum Series Fuse Rating |
30 A |
| Operating Temperature |
-40°C to +85°C |
| Dimensions |
69.37 × 44.65 × 1.18 in |
| Weight |
52.47 lb |
| Front Glass |
2.0 mm low-reflection tempered glass |
| Back Glass |
2.0 mm glass |
| Frame |
Black Anodized Aluminum |
| Junction Box |
IP68, 3 bypass diodes |
| Connector |
Stäubli MC4-EVO2 |
| Output Cable |
12 AWG, ~47.24 in |
| Mechanical Load |
75.3 PSF / 33.3 PSF (design) |
| Pallet Quantity |
36 modules per pallet |
FAQ
What advantages does the Axitec 460W GXXL Bifacial N-Type Solar Panel offer for home solar systems?
Our n type solar panels use bifacial cell technology to capture sunlight on both sides, increasing energy output. Combined with high module efficiency up to 23.02%, this panel provides reliable power generation perfect for maximizing residential rooftop solar installations.
Can you explain the durability features of this black solar panel?
We designed this black solar panel with a glass/glass module structure and a black anodized aluminum frame, enhancing resistance to weather and mechanical loads. It operates safely in temperatures from -40°C to +85°C, ensuring long-term performance in diverse outdoor environments.
Do you offer assistance with installation and system compatibility?
Yes, we provide expert guidance for integrating the Axitec 460W GXXL Bifacial panel into both grid-tied and off-grid systems. The panel’s IP68-rated junction box and Stäubli MC4-EVO2 connectors are compatible with common solar configurations, simplifying installation and ensuring system safety.
How do you handle shipping and local support for this solar panel?
We maintain local inventory in Anaheim to support fast domestic shipping across the US. Our service center is available for product inspections, technical support, and warranty inquiries, helping customers purchase and maintain high-quality solar panels with confidence.
