STC Rated Output Pmpp(W) |
460W |
|
Open Circuit Voltage Vvoc (V) |
41.97 |
|
Short Circuit Current Isc(A) |
13.75 |
|
Rated Voltage Vmp (V) |
35.36 |
|
Rated Voltage Imp (A) |
13.00 |
|
Module Efficiency |
21.26% |
| Specification | Details |
|---|---|
| Manufacturer | Aptos Solar Technology |
| Model | DNA-120-MF10-460W |
| Series | DNA Split Cell |
| Cell Technology | Mono PERC (Split Cell) |
| Cell Configuration | 120 Cells |
| Maximum Power (Pmax) | 460 W |
| Module Efficiency | Up to 21.26% |
| Maximum Power Voltage (Vmp) | 35.36 V |
| Maximum Power Current (Imp) | 13.00 A |
| Open Circuit Voltage (Voc) | 41.97 V |
| Short Circuit Current (Isc) | 13.75 A |
| Temperature Coefficient (Pmax) | -0.35% / °C |
| Temperature Coefficient (Voc) | -0.27% / °C |
| Temperature Coefficient (Isc) | +0.054% / °C |
| Nominal Operating Cell Temperature (NOCT) | 45 ± 2°C |
| Maximum System Voltage | 1500 V DC |
| Maximum Series Fuse Rating | 25 A |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 75.1 × 44.6 × 1.3 in |
| Weight | 52.9 lb |
| Glass | 3.2 mm tempered, anti-reflective coating |
| Frame | Black Frame |
| Junction Box | IP68 Rated |
| Connector | Stäubli EVO2 |
| Mechanical Load | 5400 Pa Snow / 5400 Pa Wind |
| Pallet Quantity | 31 modules per pallet |
